The grader graphite bronze bushing, also known as wrapped bronze bushings, is a highly reliable component widely used in various industries. Its unique combination of graphite and bronze alloys offers exceptional properties that make it ideal for demanding applications.
The graphite content in these bushings provides excellent lubrication properties, reducing friction and wear during operation. This results in longer service life and reduced maintenance requirements, making the grader graphite bronze bushing a cost-effective solution.
The bronze alloy used in these bushings offers high strength and corrosion resistance. This ensures that the bushing can withstand harsh operating conditions and protect against damage from corrosive environments.
The wrapped construction of the grader graphite bronze bushing further enhances its reliability. The wrapping process ensures that the graphite and bronze are tightly bonded tog, creating a strong and uniform bearing surface. This provides better support and stability for the rotating shaft or other moving components.
Due to their excellent properties and reliability, grader graphite bronze bushings are in high demand in various industries, including mining, construction, and heavy machinery. They are commonly used in crushers, conveyors, pumps, and other equipment that requires high-performance bearings.
In conclusion, the grader graphite bronze bushing is a wrapped bronze bushing that offers exceptional reliability and performance. Its unique combination of graphite and bronze alloys, along with the wrapped construction, provides excellent lubrication, strength, and corrosion resistance. This makes it a highly demanded component in various industries.
Grader bronze graphite bushings | Metal-Polymer Plain Bearings
Bronze Bearings is a self-lubricating bearing which is based on high-strength copper alloy and which needs to process holes in its working surface and fill in solid lubricant according to the working conditions. This copper alloy inlaid solid lubricant bearing combines the high load-bearing and wear resistance of the copper alloy. The self-lubricating properties of the solid lubricant make it unnecessary to maintain during use. It is especially suitable for high load, high temperature, low speed and other parts that cannot be oiled or difficult to form an oil film.
| item | value |
| Applicable Industries | Graphite plugged bronze flange bearing, Graphite plugged brass flange bearings, Self-lubricating graphite bronze bearings |
| Place of Origin | South Korea |
| Brand Name | viiplus |
| Model Number | graphite plugged bronze bushing |
| Material | C86300 with graphite plugs |
| Model No. | customized |
| Type | Flange bushing |
| Standard | KS/ASTM/DIN/JIS/EN |
| Features | Excellent performance in high-load and low-speed motion |
| Certification | ISO9001, ISO14001 |
| Package | Plastic Bag, Carton, Wooden Pallet/Wooden Box |
| Payment | Negotiable |
| Sample | Available |
| Marking | Available with number and english charater |
Application requirements
For large civil engineering projects, heavy equipment such as bulldozers and bulldozers move the soil and aggregate in place to form a rough grade surface, from which the electric grader provides a flat or sloping surface to obtain the final surface.
This smooth surface is produced by long blades attached to the grader, which are precisely adjusted in position and Angle by means of a hydraulic cylinder and a link and pivot system.
Agricultural Grader bearing solutions
Heavy bearing - advantage
High performance, heavy duty sliding bearings have the following advantages: environmentally friendly drying operation, can eliminate grease on the soil pollution
Reduce equipment costs without the need for lubrication systems, channels, hoses, joints/parts and expensive oil seals
Reduced cost of ownership, maintenance-free operation and extended service life
Higher productivity and less downtime for bearing maintenance and replacement
Lightweight, compact and rugged bearing design with excellent impact resistance, coaxiality and wear
Composite bearing structure provides excellent chemical corrosion resistance
Application requirements
For large civil engineering projects, heavy equipment such as bulldozers and bulldozers move the soil and aggregate in place to form a rough grade surface, from which the electric grader provides a flat or sloping surface to obtain the final surface.
This smooth surface is produced by long blades attached to the grader, which are precisely adjusted in position and Angle by means of a hydraulic cylinder and a link and pivot system.
| Density | 8.0 g/cm3 |
| Hardness | >210 HB |
| Tensile strength | >750 N/mm2 |
| Yeild strength | >450 N/mm2 |
| Elongation | >8 |
| Coefficient of linear expansion | 1.9x10-5/°C |
| Operating temperature | -40°C~+300°C |
| Max. Dynamic Load | 120 |
| Max. Speed | Dry | 0.4 m/s |
| Oil | 1.0 m/s |
| Max. PV limit | Dry | 1.5 N/mm2.m/s |
| Oil | 3.25 N/mm2.m/s |
| Friction | Dry | 0.12~0.16 μ |
| Oil | 0.03~0.08 μ |
